AGM Long Life LPL series
LEOCH Premium Long Life batteries, LPL series, are AGM Valve-Regulated Lead-Acid batteries that have been optimized for a wide range of security, emergency lighting and other general purpose applications requiring Long Floating Life from the batteries. Engineered for long life applications LPL series are classified as long life, according to Eurobat and offer up to 12 years float life.
CE Marking Statement
LEOCH batteries do not bear the CE mark. The “CE” mark indicates the conformity of a product with an EC Directive applicable to that product and is a declaration that the product conforms to all EC regulations and provisions, and that the appropriate conformity assessment procedures have been completed. Batteries are covered by a different directive (Battery Directive 2006/66/EC) and as such the CE mark is not required on any LEOCH lead acid battery. LEOCH batteries do conform with all the relevant EC directives and regulations and as such are marked with the appropriate symbols but not bear CE marking which is inappropriate to be marked on lead-acid batteries.
AGM Long Life LPL series
LEOCH Premium Long Life batteries, LPL series, are AGM Valve-Regulated Lead-Acid batteries that have been optimized for a wide range of security, emergency lighting and other general purpose applications requiring Long Floating Life from the batteries. Engineered for long life applications LPL series are classified as long life, according to Eurobat and offer up to 12 years float life.
CE Marking Statement
LEOCH batteries do not bear the CE mark. The “CE” mark indicates the conformity of a product with an EC Directive applicable to that product and is a declaration that the product conforms to all EC regulations and provisions, and that the appropriate conformity assessment procedures have been completed. Batteries are covered by a different directive (Battery Directive 2006/66/EC) and as such the CE mark is not required on any LEOCH lead acid battery. LEOCH batteries do conform with all the relevant EC directives and regulations and as such are marked with the appropriate symbols but not bear CE marking which is inappropriate to be marked on lead-acid batteries.
Wide model range including 2V, 6V and 12V cells and blocks with capacities ranging from 4.5Ah up to 3000Ah
Long Life (up to 12 years for 6V & 12V blocks) and Very Long Life (up to 16 years for 2V cells) classified, according to Eurobat
Multiple terminal options (*available on selected models) and M suffix 2V cells available for horizontal installation for reduced installation footprint
Unique anti-explosion one-way vent valve design to minimize water loss and increase safety
Thick plates, with a special pasting formula, ensure long service life
ABS case UL94-HB (UL94-V0 Optional) is used for increased container strength
| Model | Nominal Voltage (V) | Rated Capacity 20Hr @ 1.8V/cell (AH) | Rated Capacity 10Hr @ 1.8V/cell (AH) | Approx. Dimensions | Approx. Weight | Terminal Type | ||||||||
| L | W | H | TH | |||||||||||
| mm | in. | mm | in. | mm | in. | mm | in. | kg | lbs | |||||
| LPL2-200M | 2 | 200 | 90.00 | 3.54 | 181.00 | 7.13 | 350.00 | 13.78 | 365.00 | 14.37 | 12.40 | 27.34 | T11(M8) | |
| LPL2-300M | 2 | 300 | 124.00 | 4.88 | 181.00 | 7.13 | 350.00 | 13.78 | 365.00 | 14.37 | 18.00 | 39.68 | T11(M8) | |
| LPL2-400M | 2 | 400 | 158.00 | 6.22 | 181.00 | 7.13 | 350.00 | 13.78 | 365.00 | 14.37 | 22.70 | 50.04 | T11(M8) | |
| LPL2-500M | 2 | 500 | 191.00 | 7.52 | 181.00 | 7.13 | 350.00 | 13.78 | 365.00 | 14.37 | 28.40 | 62.61 | T11(M8) | |
| LPL2-600M | 2 | 600 | 225.00 | 8.86 | 181.00 | 7.13 | 350.00 | 13.78 | 365.00 | 14.37 | 33.10 | 72.97 | T11(M8) | |
| LPL2-800M | 2 | 800 | 303.00 | 11.93 | 181.00 | 7.13 | 350.00 | 13.78 | 365.00 | 14.37 | 44.50 | 98.11 | T11(M8) | |
| LPL2-1000M | 2 | 1000 | 370.00 | 14.57 | 181.00 | 7.13 | 350.00 | 13.78 | 365.00 | 14.37 | 55.80 | 123.02 | T11(M8) | |
| LPL6-6.5 | 6 | 6.5 | 150.00 | 5.91 | 34.00 | 1.34 | 94.00 | 3.70 | 100.00 | 3.94 | 1.26 | 2.78 | T1/T2 | |
| LPL6-9.0 | 6 | 9 | 151.00 | 5.94 | 50.50 | 1.99 | 94.00 | 3.70 | 100.00 | 3.94 | 1.70 | 3.75 | T1/T2 | |
| LPL6-11 | 6 | 11 | 151.00 | 5.94 | 50.50 | 1.99 | 94.00 | 3.70 | 100.00 | 3.94 | 1.95 | 4.30 | T1/T2 | |
| LPL6-18 | 6 | 18 | 157.00 | 6.18 | 83.00 | 3.27 | 125.00 | 4.92 | 125.00 | 4.92 | 3.21 | 7.08 | T3-A | |
| LPL12-7.0 | 12 | 7 | 151.00 | 5.94 | 65.00 | 2.56 | 93.50 | 3.68 | 99.50 | 3.92 | 2.50 | 5.51 | T1/T2 | |
| LPL12-12 | 12 | 12 | 151.00 | 5.94 | 98.00 | 3.86 | 95.00 | 3.74 | 101.00 | 3.98 | 3.85 | 8.49 | T1/T2 | |
| LPL12-18 | 12 | 18 | 181.50 | 7.15 | 76.50 | 3.01 | 167.50 | 6.59 | 167.50 | 6.59 | 5.70 | 12.57 | T3 | |
| LPL12-24 | 12 | 24 | 166.00 | 6.54 | 175.00 | 6.89 | 125.00 | 4.92 | 125.00 | 4.92 | 7.80 | 17.20 | T12-I(M5) | |
| LPL12-28H | 12 | 28 | 164.00 | 6.46 | 125.00 | 4.92 | 176.00 | 6.93 | 176.00 | 6.93 | 9.10 | 20.06 | T3-A | |
| LPL12-28 | 12 | 28 | 166.00 | 6.54 | 175.00 | 6.89 | 125.00 | 4.92 | 125.00 | 4.92 | 8.60 | 18.96 | T12(M5) | |
| LPL6-180 | 6 | 180 | 306.00 | 12.05 | 168.00 | 6.61 | 222.00 | 8.74 | 228.00 | 8.98 | 30.30 | 66.80 | T8(M6) | |
| LPL12-38 | 12 | 38 | 197.00 | 7.76 | 165.00 | 6.50 | 170.00 | 6.69 | 170.00 | 6.69 | 12.70 | 28.00 | T6(M6) | |
| LPL12-40 | 12 | 40 | 197.00 | 7.76 | 165.00 | 6.50 | 170.00 | 6.69 | 170.00 | 6.69 | 14.50 | 31.97 | T6(M6) | |
| LPL12-45 | 12 | 45 | 197.00 | 7.76 | 165.00 | 6.50 | 170.00 | 6.69 | 170.00 | 6.69 | 14.20 | 31.31 | T6(M6) | |
| LPL12-55 | 12 | 55 | 229.00 | 9.02 | 138.00 | 5.43 | 210.00 | 8.27 | 230.00 | 9.06 | 17.70 | 39.02 | T9 | |
| LPL12-60 | 12 | 60 | 260.00 | 10.24 | 168.00 | 6.61 | 210.00 | 8.27 | 216.00 | 8.50 | 20.70 | 45.64 | T6(M6) | |
| LPL12-65 | 12 | 65 | 348.00 | 13.70 | 167.00 | 6.57 | 178.00 | 7.01 | 178.00 | 7.01 | 21.00 | 46.30 | T6(M6) | |
| LPL12-70 | 12 | 70 | 348.00 | 13.70 | 167.00 | 6.57 | 178.00 | 7.01 | 178.00 | 7.01 | 23.10 | 50.93 | T6(M6) | |
| LPL12-75 | 12 | 75 | 260.00 | 10.24 | 168.00 | 6.61 | 208.00 | 8.19 | 214.00 | 8.43 | 22.70 | 50.04 | T6(M6) | |
| LPL12-90H | 12 | 90 | 330.00 | 12.99 | 173.00 | 6.81 | 212.00 | 8.35 | 220.00 | 8.66 | 29.50 | 65.04 | T11(M8) | |
| LPL12-100 | 12 | 100 | 330.00 | 12.99 | 173.00 | 6.81 | 212.00 | 8.35 | 220.00 | 8.66 | 30.50 | 67.24 | T11(M8) | |
| LPL12-120 | 12 | 120 | 408.00 | 16.06 | 177.00 | 6.97 | 225.00 | 8.86 | 225.00 | 8.86 | 36.30 | 80.03 | T11(M8) | |
| LPL12-150 | 12 | 150 | 483.00 | 19.02 | 170.00 | 6.69 | 238.50 | 9.39 | 238.50 | 9.39 | 46.50 | 102.51 | T11(M8) | |
| LPL12-200 | 12 | 200 | 522.00 | 20.55 | 240.00 | 9.45 | 218.00 | 8.58 | 224.00 | 8.82 | 62.30 | 137.35 | T11(M8) | |
| LPL12-225 | 12 | 225 | 522.00 | 20.55 | 268.00 | 10.55 | 220.00 | 8.66 | 226.00 | 8.90 | 70.50 | 155.43 | T11(M8) | |
| LPL12-250 | 12 | 250 | 522.00 | 20.55 | 268.00 | 10.55 | 220.00 | 8.66 | 226.00 | 8.90 | 76.50 | 168.65 | T11(M8) | |
| LPL2-100 | 2 | 100 | 134.00 | 5.28 | 67.00 | 2.64 | 59.50 | 2.34 | 65.50 | 2.58 | 5.80 | 12.79 | T6(M6) | |
| LPL2-200 | 2 | 200 | 170.00 | 6.69 | 110.00 | 4.33 | 328.00 | 12.91 | 348.00 | 13.70 | 13.50 | 29.76 | T11(M8) | |
| LPL2-250(PP) | 2 | 250 | 170.50 | 6.71 | 110.50 | 4.35 | 325.50 | 12.81 | 345.50 | 13.60 | 15.60 | 34.39 | T11(M8) | |
| LPL2-300 | 2 | 300 | 170.00 | 6.69 | 150.00 | 5.91 | 328.00 | 12.91 | 348.00 | 13.70 | 18.80 | 41.45 | T11(M8) | |
| LPL2-400 | 2 | 400 | 210.00 | 8.27 | 175.00 | 6.89 | 330.00 | 12.99 | 350.00 | 13.78 | 25.50 | 56.22 | T11(M8) | |
| LPL2-500 | 2 | 500 | 240.00 | 9.45 | 175.00 | 6.89 | 330.00 | 12.99 | 350.00 | 13.78 | 30.00 | 66.14 | T11(M8) | |
| LPL2-500(PP) | 2 | 500 | 239.00 | 9.41 | 174.00 | 6.85 | 327.00 | 12.87 | 347.00 | 13.66 | 31.00 | 68.34 | T11(M8) | |
| LPL2-600 | 2 | 600 | 300.00 | 11.81 | 175.00 | 6.89 | 330.00 | 12.99 | 350.00 | 13.78 | 37.00 | 81.57 | T11(M8) | |
| LPL2-800 | 2 | 800 | 410.00 | 16.14 | 175.00 | 6.89 | 330.00 | 12.99 | 350.00 | 13.78 | 50.40 | 111.11 | T11(M8) | |
| LPL2-1000 | 2 | 1000 | 475.00 | 18.70 | 175.00 | 6.89 | 328.00 | 12.91 | 350.00 | 13.78 | 60.00 | 132.28 | T11(M8) | |
| LPL2-1500 | 2 | 1500 | 403.00 | 15.87 | 354.00 | 13.94 | 339.00 | 13.35 | 349.00 | 13.74 | 97.80 | 215.61 | T11(M8) | |
| LPL2-2000 | 2 | 2000 | 490.00 | 19.29 | 350.00 | 13.78 | 339.00 | 13.35 | 349.00 | 13.74 | 121.00 | 266.76 | T11(M8) | |
| LPL2-3000 | 2 | 3000 | 709.00 | 27.91 | 350.00 | 13.78 | 337.00 | 13.27 | 347.00 | 13.66 | 183.00 | 403.45 | T11(M8) | |
