Deep Cycle AGM LPC series
Leoch Deep Cycle batteries, LPC series, are AGM Valve-Regulated Lead-Acid batteries that have been designed and optimized for cyclic intensive applications, offer high resilience for deep discharge recovery.
CE Marking Statement
Leoch batteries do not bear the CE mark. The “CE” mark indicates the conformity of a product with an EC Directive applicable to that product and is a declaration that the product conforms to all EC regulations and provisions, and that the appropriate conformity assessment procedures have been completed. Batteries are covered by a different directive (Battery Directive 2006/66/EC) and as such the CE mark is not required on any Leoch lead acid battery. Leoch batteries do conform with all the relevant EC directives and regulations and as such are marked with the appropriate symbols but not bear CE marking which is inappropriate to be marked on lead-acid batteries.
Deep Cycle AGM LPC series
Leoch Deep Cycle batteries, LPC series, are AGM Valve-Regulated Lead-Acid batteries that have been designed and optimized for cyclic intensive applications, offer high resilience for deep discharge recovery.
CE Marking Statement
Leoch batteries do not bear the CE mark. The “CE” mark indicates the conformity of a product with an EC Directive applicable to that product and is a declaration that the product conforms to all EC regulations and provisions, and that the appropriate conformity assessment procedures have been completed. Batteries are covered by a different directive (Battery Directive 2006/66/EC) and as such the CE mark is not required on any Leoch lead acid battery. Leoch batteries do conform with all the relevant EC directives and regulations and as such are marked with the appropriate symbols but not bear CE marking which is inappropriate to be marked on lead-acid batteries.
Designed and optimized for cyclic intensive applications, offer high resilience for deep discharge recovery
Reliable sealing structure, unique valve design and AGM technology reduces the risk of leakage
Uniqueness of design and additives used, recovery of 90% of its capacity may be restored even after a complete down-to-0V discharge
Working temperature environment -20°C~+55°C
Higher charge acceptance compared to flooded batteries
High strength Absorbed Glass Mat (AGM) separator for reduced electrolyte loss and longer service life
| Model | Nominal Voltage (V) | Rated Capacity (AH) | Short Current (A) | IR(mΩ) | Approx. Dimensions | Approx. Weight | Terminal Type | |||||||||
| L | W | H | TH | |||||||||||||
| 20HR | 10HR | mm | in. | mm | in. | mm | in. | mm | in. | kg | lbs. | |||||
| LPC6-5.6 | 6 | 5.5 | 154 | 16 | 70.00 | 2.76 | 47.00 | 1.85 | 100.00 | 3.94 | 106.00 | 4.17 | 0.90 | 1.98 | T1/T2 | |
| LPC6-13 | 6 | 14 | 392 | 10 | 151.00 | 5.94 | 50.50 | 1.99 | 94.00 | 3.70 | 100.00 | 3.94 | 1.90 | 4.19 | T1/T2 | |
| LPC12-3.5 | 12 | 3.5 | 98 | 40 | 134.00 | 5.28 | 67.00 | 2.64 | 59.50 | 2.34 | 65.50 | 2.58 | 1.35 | 2.98 | T1 | |
| LPC12-5.6 | 12 | 5.4 | 151.2 | 25 | 90.00 | 3.54 | 70.00 | 2.76 | 101.00 | 3.98 | 107.00 | 4.21 | 1.80 | 3.97 | T1/T2 | |
| LPC12-8.0 | 12 | 8 | 224 | 20 | 151.00 | 5.94 | 65.00 | 2.56 | 93.50 | 3.68 | 99.50 | 3.92 | 2.50 | 5.51 | T2 | |
| LPC12-12 | 12 | 12 | 336 | 16 | 151.00 | 5.94 | 98.00 | 3.86 | 95.00 | 3.74 | 101.00 | 3.98 | 3.43 | 7.56 | T1/T2 | |
| LPC12-13 | 12 | 14 | 392 | 14 | 151.00 | 5.94 | 98.00 | 3.86 | 95.00 | 3.74 | 101.00 | 3.98 | 3.78 | 8.33 | T1/T2 | |
| LPC12-18 | 12 | 20 | 560 | 16 | 181.50 | 7.15 | 76.50 | 3.01 | 167.50 | 6.59 | 167.50 | 6.59 | 5.65 | 12.46 | T3 | |
| LPC12-20 | 12 | 20 | 560 | 14 | 181.50 | 7.15 | 76.50 | 3.01 | 167.50 | 6.59 | 167.50 | 6.59 | 6.00 | 13.23 | M5 | |
| LPC12-24 | 12 | 26 | 728 | 12 | 166.00 | 6.54 | 175.00 | 6.89 | 126.00 | 4.96 | 126.00 | 4.96 | 8.57 | 18.89 | M5 | |
| LPC12-24H | 12 | 28 | 700 | 14 | 164.00 | 6.46 | 125.00 | 4.92 | 176.00 | 6.93 | 176.00 | 6.93 | 9.10 | 20.06 | T3-A | |
| LPC12-26 | 12 | 26 | 650 | 14 | 166.00 | 6.54 | 175.00 | 6.89 | 125.00 | 4.92 | 125.00 | 4.92 | 7.80 | 17.20 | T3 | |
| LPC12-33 | 12 | 33 | 825 | 12 | 195.00 | 7.68 | 130.00 | 5.12 | 164.00 | 6.46 | 178.00 | 7.01 | 10.15 | 22.38 | T5 | |
| LPC12-38 | 12 | 38 | 950 | 10 | 197.00 | 7.76 | 165.00 | 6.50 | 170.00 | 6.69 | 170.00 | 6.69 | 12.00 | 26.46 | M6 | |
| LPC12-42 | 12 | 42 | 1050 | 9 | 197.00 | 7.76 | 165.00 | 6.50 | 170.00 | 6.69 | 170.00 | 6.69 | 14.10 | 31.09 | M6 | |
| LPC12-50 | 12 | 50 | 1250 | 9 | 257.00 | 10.12 | 132.00 | 5.20 | 200.00 | 7.87 | 200.00 | 7.87 | 17.60 | 38.80 | M6 | |
| LPC12-55 | 12 | 55 | 1375 | 9 | 229.00 | 9.02 | 138.00 | 5.43 | 205.00 | 8.07 | 211.00 | 8.31 | 16.20 | 35.71 | M6 | |
| LPC12-75 | 12 | 75 | 1875 | 6.6 | 260.00 | 10.24 | 168.00 | 6.61 | 208.00 | 8.19 | 214.00 | 8.43 | 22.30 | 49.16 | M6 | |
| LPC12-90 | 12 | 90 | 2070 | 5.5 | 306.00 | 12.05 | 168.00 | 6.61 | 208.00 | 8.19 | 214.00 | 8.43 | 26.80 | 59.08 | M6 | |
| LPC12-100 | 12 | 100 | 2000 | 4.9 | 330.00 | 12.99 | 173.00 | 6.81 | 212.00 | 8.35 | 220.00 | 8.66 | 30.60 | 67.46 | M8 | |
| LPC12-120 | 12 | 120 | 2400 | 3.6 | 408.00 | 16.06 | 177.00 | 6.97 | 225.00 | 8.86 | 225.00 | 8.86 | 37.30 | 82.23 | M8 | |
| LPC12-150 | 12 | 150 | 3000 | 3.5 | 483.00 | 19.02 | 170.00 | 6.69 | 238.50 | 9.39 | 238.50 | 9.39 | 43.20 | 95.24 | M8 | |
